PD2450W-IS V2

802.3bt 24V 5A 120W Industrial PoE Splitter (Isolated)

• IEEE 802.3af / 802.3at / 802.3bt PoE standard compliant
• High-power PoE output up to 120 W
• Stable DC output: 24 V / 5 A (terminal block)
• 10/100/1000 Mbps Gigabit Ethernet data rate
• PoE OUT pin configuration: 12+ 36- / 45+ 78-
• 1× PoE input, 1× Data OUT and 1× DC OUT (terminal block)
• Clear LED indicators for PoE input and network / link status
• Lightning protection with isolation (3 KV / 1.5 KV)
• Industrial-grade protection: IP40 rated enclosure
• Wide operating temperature: -40°C ~ 85°C
• Compact and rugged design (105 × 90 × 30 mm, 0.45 kg)

PD2450W-IS V2 Overview

The PD2450W-IS is an industrial PoE splitter compliant with IEEE 802.3af / at / bt, delivering up to 120 W of PoE power output. It takes a single PoE input and provides one Data OUT port together with one DC OUT (terminal block), supporting 10/100/1000 Mbps Ethernet transmission over standard UTP cabling. Designed for harsh industrial environments, the unit features an IP40 protection rating, a wide operating temperature range of -40°C to 85°C, and lightning protection with isolation, making it suitable for outdoor and industrial power-over-ethernet deployments where reliable power extraction is required.

PD2450W-IS V2 Specification

Item	Specification
Model Number	PD2450W-IS
Product Name	802.3bt 120W Industrial PoE Splitter (Isolated)
Ports	1× PoE IN + 1× DATA OUT + 1× DC OUT (terminal block)
Data Rate	10/100/1000 Mbps
PoE Protocol	IEEE 802.3af / at / bt compliant
PoE OUT Pin	12+ 36- / 45+ 78-
PoE Power Output	120 W
Output Parameter	24 V / 5 A
Transmission Medium	10BASE-T: UTP CAT 3, 4, 5 (max 150 m) 100BASE-TX: UTP CAT 5, 5e (max 150 m) 1000BASE-TX: UTP CAT 5e, 6 (max 150 m)
LED Indicator	PoE IN: Orange / PoE input, Green / Network connection DATA OUT: Orange / 100M, Green / 1000M
Lightning Protection	3 KV / 1.5 KV (isolation)
Protection Class	IP40
Working Temperature	-40°C ~ 85°C
Dimensions (Product)	105 × 90 × 30 mm
Weight	0.45 kg
